郵件伺服器 Part-3-4：Mailscanner-mrtg

发布于 2008-10-17
by

3.前情提要：郵件伺服器Part-2：MailScanner+ClamAV+SpamAssassin

4.前情提要：郵件伺服器Part-3：MailScanner-mrtg

系統使用CentOS 5.1
郵件伺服器全系列：+Dovecot+SASL+Procmail+Postgrey+Mailscanner+Spamassassin+ClamAV+Mailscanner-mrtg+MailWatch+Openwebmail+MySPAM

Mailscanner-mrtg可偵測伺服器各項資源、效能並產生紀錄網頁

1.安裝SNMP

yum -y install net-snmp net-snmp-utils


2.SNMP的設定

vim /etc/snmp/snmpd.conf


com2sec local localhost public
com2sec mynetwork 192.168.0.0/24 public
group MyRWGroup v1 local
group MyROGroup v1 mynetwork
group MyRWGroup v2c local
view systemview included .1.3.6.1.2.1.1
view systemview included .1.3.6.1.2.1.25.1.1
view all included .1 80
access MyROGroup “” any noauth prefix all none none
access MyRWGroup “” any noauth prefix all all all
syslocation Unknown (edit /etc/snmp/snmpd.conf)
syscontact Root (configure /etc/snmp/snmp.local.conf)
pass .1.3.6.1.4.1.4413.4.1 /usr/bin/ucd5820stat



3.啟動SNMP

/etc/rc.d/init.d/snmpd start
chkconfig snmpd on
chkconfig –list snmpd


4.安裝MRTG

yum -y install mrtg


5.安裝Mailscanner-MRTG
下載http://sourceforge.net/project/showfiles.php?group_id=68848

rpm -ivh mailscanner-mrtg-0.10.00-1.noarch.rpm


6.修改Mailscanner-MRTG設定

vim /etc/MailScanner/mailscanner-mrtg.conf


　修改下列參數:

MTA = postfix (設定使用的MTA)
Incoming Queue Dir = /var/spool/postfix/hold (收信佇列目錄)
Outgoing Queue Dir = /var/spool/postfix/incoming (寄信佇列目錄)

MailScanner Work Directory = /var/spool/MailScanner/incoming (MailScanner目錄)
Spool Directory = /var/spool/mailscanner-mrtg (MailScanner-mrtg目錄)
# MailScanner Work Directory及Spool Directory是使用df指令來取得磁碟空間，如果沒有獨立的分割區，可以直接改成/var

Use SNMP = yes (使用SNMP)
SNMP Community = public (SNMP設定)
#CPU負載、記憶體用量、網路流量需要使用SNMP


vim /etc/mrtg/mailscanner-mrtg.cfg


Workdir: /var/www/html/mailscanner-mrtg (Mailscanner-MRTG網頁目錄)
IconDir: /mrtg/
WriteExpires: Yes
Interval: 5
Refresh: 300
Language: big5 (設定網頁使用的語系)


7.產生index.html網頁

indexmaker –output=/var/www/html/mailscanner-mrtg/index.html /etc/mrtg/mailscanner-mrtg.cfg


8.測試參數檔

mrtg /etc/mrtg/mailscanner-mrtg.cfg


　需重覆執行到沒有錯誤，如超過三次請檢查設定檔

9.完成後可以在以下看到流量:




備註：
◎如MRTG的圖示無法顯示，請修改httpd設定

vim /etc/httpd/conf.d/mrtg.conf


Allow from localhost改成Allow from all


◎如要記錄MailScanner處理速度(Processing Speed)，需修改MailScanner設定

vim /etc/MailScanner/MailScanner.conf


Log Speed = yes

MailWatch蒐集MailScanner郵件過濾的判定紀錄，可用於分析、管理規則的設定

1.安裝MYSQL及相關元件

yum install mysql mysql-server mod_auth_mysql perl-DBD-MySQL


2.安裝PHP及相關元件

yum install php php-gd php-pear php-mysql php-devel



3.設定啟動服務

chkconfig httpd on
chkconfig mysqld on


4.啟動服務

service mysqld start
service httpd start


5.設定MYSQL密碼

/usr/bin/mysqladmin -u root password ‘xxxxxx’


6.設定PHP

vim /etc/php.ini


short_open_tag = On
safe_mode = Off
register_globals = Off
magic_quotes_gpc = On
magic_quotes_runtime = Off
session.auto_start = 0


7.安裝MailWatch
下載http://sourceforge.net/project/showfiles.php?group_id=87163

tar -zxvf mailwatch-1.0.4.tar.gz


8.建立資料庫

cd /usr/local/src/mailwatch-1.0.4/

mysql -p < create.sql


產生mailscanner資料庫並建立資料表

9.修改MailWatch資料庫設定

vim MailWatch.pm


my($db_name) = ‘mailscanner’; (資料庫名稱)
my($db_host) = ‘localhost’; (資料庫位置)
my($db_user) = ‘root’; (使用者名稱)
my($db_pass) = ‘xxxxxx′; (使用者密碼)


10.複製設定檔

cp MailWatch.pm /usr/lib/MailScanner/MailScanner/CustomFunctions/


11.新增網頁使用者

mysql mailscanner -u root -p
Enter password: ******


mysql> INSERT INTO users VALUES (‘root’,md5(‘xxxxxx’),’root’,'A’,’0′,’0′,’0′,’0′,’0′);


11.設置網頁檔案

mv mailscanner /var/www/html/


12.修改網頁權限

cd /var/www/html/mailscanner

chown root:apache images

chmod ug+rwx images

chown root:apache images/cache

chmod ug+rwx images/cache


12.複製設定檔

cp conf.php.example conf.php


13.設定conf.php

vim conf.php


define(DB_TYPE, ‘mysql’);
define(DB_USER, ‘root’);
define(DB_PASS, ‘xxxxxx’);
define(DB_HOST, ‘localhost’);
define(DB_NAME, ‘mailscanner’);


14.設定MailScanner

vim /etc/MailScanner/MailScanner.conf


Quarantine User = root
Quarantine Group = apache (this should be the same group as your web server)
Quarantine Permissions = 0660
Quarantine Whole Message = yes
Quarantine Whole Message As Queue Files = no
Detailed Spam Report = yes
Include Scores In SpamAssassin Report = yes
Always Looked Up Last = &MailWatchLogging


15.設定黑白名單

vim /usr/local/src/mailwatch-1.0.4/SQLBlackWhiteList.pm


my($db_name) = ‘mailscanner’;
my($db_host) = ‘localhost’;
my($db_user) = ‘root’;
my($db_pass) = ‘!Q@W#E$R’;


cp /usr/local/src/mailwatch-1.0.4/SQLBlackWhiteList.pm /usr/lib/MailScanner/MailScanner/CustomFunctions/


vim /etc/MailScanner/MailScanner.conf


Is Definitely Not Spam = &SQLWhitelist
Is Definitely Spam = &SQLBlacklist


16. 修改SpamAssassin設定

vim /etc/MailScanner/spam.assassin.prefs.conf


加入

bayes_path /etc/MailScanner/bayes/bayes
bayes_file_mode 0660


17.建立新的bayes目錄

mkdir /etc/MailScanner/bayes
chown root:apache /etc/MailScanner/bayes
chmod g+rws /etc/MailScanner/bayes


18.複製已經存在的bayes資料庫

cp /root/.spamassassin/bayes_* /etc/MailScanner/bayes
chown root:apache /etc/MailScanner/bayes/bayes_*
chmod g+rw /etc/MailScanner/bayes/bayes_*


19.測試SpamAssassin

spamassassin -D -p /etc/MailScanner/spam.assassin.prefs.conf –lint


20.重新啟動MailScanner

service MailScanner restart



備註：
◎網頁中文化

說明 http://csc.ocean-pioneer.com/modules/news/article.php?storyid=17
檔案 http://csc.ocean-pioneer.com/docum/mailscanner.tar.gz
下載後覆蓋即可，中文測試時有些設定功能會失效，可能是版本不同造成的。


◎改網頁編碼
　若顯示Big5中文會出現亂碼，可以在/etc/httpd/conf.d下建立設定檔案

vim /etc/httpd/conf.d/mailwatch.conf


Alias /mailscanner /var/www/html/mailscanner

<Location /mailscanner>
Order allow,deny
allow from all
AddDefaultCharset Big5
</Location>


本文来自:唉呦~MIS先生

Share
[ 1 条评论 ]

郵件伺服器 Part-2：MailScanner+ClamAV+SpamAssassin

发布于 2008-10-17
by

前情提要：郵件伺服器 Part-1：+Dovecot+SASL+Procmail

系統使用CentOS 5.1
郵件伺服器全系列：Postfix+Dovecot+SASL+Procmail+Postgrey+Mailscanner+Spamassassin+ClamAV+Mailscanner-mrtg+MailWatch+Openwebmail+MySPAM

MailScanner+ClamAV+SpamAssassin可涵蓋郵件的內容及病毒過濾
A.安裝mailscanner
1.安裝相關元件

yum install patch rpm-build
yum install perl-MIME-tools
yum install gcc perl-Archive-Zip

2.下載MailScanner

cd /usr/local/src
elinks http://www.mailscanner.info/downloads.html

下載Version 4.70.7-1 for RedHat, Fedora and Mandrake (and other RPM-based distributions)

3.安裝MailScanner

cd /usr/local/src
tar -zxvf MailScanner-4.70.7-1.rpm.tar.gz
cd MailScanner-4.70.7-1
./install.sh

4.啟動MailScanner

service postfix stop
chkconfig postfix off
chkconfig –level 2345 MailScanner on
service MailScanner start

5.設定MailScanner設定檔案

vim /etc/MailScanner/MailScanner.conf

基本設定
Run As User = postfix (啟動的使用者)
Run As Group = postfix (啟動的群組)
Incoming Queue Dir = /var/spool/postfix/hold (收信佇列)
Outgoing Queue Dir = /var/spool/postfix/incoming (寄信佇列)
MTA = postfix (使用的MTA)
Max Children = 5 (產生子程序的上限)
Virus Scanning = yes (啟動病毒掃瞄)
Virus Scanners = clamav (設定掃毒套件，多個掃毒套件時以空白字元分隔)
Spam Checks = yes (啟動SPAM掃瞄)
Use SpamAssassin = yes (使用 SpamAssassin 偵測SPAM)
SpamAssassin Site Rules Dir = /etc//spamassassin (SpamAssassin規則檔路徑)
Deliver Unparsable TNEF = yes (增加使用Outlook的相容性)
High Scoring Spam Actions = deliver header “X-Spam-Status: Yes” (高積分時在header標記X-Spam)


效能調教(可參考修改)
Max Unscanned Bytes Per Scan = 300m (每批不被掃瞄大小的上限)
Max Unsafe Bytes Per Scan = 150m (每批被掃瞄大小的上限)
Max Unscanned Messages Per Scan = 300 (每批不被掃瞄數目的上限)
Max Unsafe Messages Per Scan = 300 (每批被掃瞄數目的上限)

其他設定
Spam Subject Text = **SPAM** (普通SPAM的附加標題)
High Scoring Spam Subject Text = **SPAM** (高分SPAM的附加標題)

Send Notices = no (感染信件通知管理員)
Notices Include Full Headers = no (通知信件包含完整表頭)

Required SpamAssassin Score = 6 (普通SPAM積分)
High SpamAssassin Score = 10 (高SPAM積分)

Delivery Method = batch (批次掃描)

6.附件過濾設定(依需求調整)
　過濾附件副檔名屬性設定

vim /etc/MailScanner/filename.rules.conf

　過濾附件類型屬性設定

vim /etc/MailScanner/filetype.rules.conf

7.佇列環境配置

chown postfix.postfix /var/spool/MailScanner/incoming
chown postfix.postfix /var/spool/MailScanner/quarantine

8.設定postfix將信件移到佇列

vim /etc/postfix/main.cf


header_checks = regexp:/etc/postfix/header_checks

vim /etc/postfix/header_checks


/^Received:/ HOLD

9.規則設定
　設定郵件白名單

vim /etc/MailScanner/rules/spam.whitelist.rules



10.重新啟動MailScanner

service MailScanner restart





B.安裝SpamAssassin+clamav

yum install spamassassin


1.安裝razor

yum install perl-Razor-Agent


2.安裝pyzor

yum install pyzor


3.安裝dcc

cd /usr/local/src
elinks www.rhyolite.com/anti-spam/dcc/source

　下載dcc-dccd.tar.Z

tar -xzvf dcc-dccd.tar.Z
cd dcc-dccd-1.3.39/
./configure
make
make install



4.安裝unrar

yum install unrar


5.安裝ClamAV

yum install clamav-db clamav clamd


6.排程更新clamav病毒碼
　(每天0,12點更新病毒碼)

vim /etc/crontab


　0 0,12 * * * root /usr/bin/freshclam

7.啟動spamassassin

chkconfig spamassassin on
service spamassassin start


8.修改資料夾權限

chown postfix /var/spool/postfix



C.規則設定
1.spamassassin預設規則

vim /etc/mail/spamassassin/local.cf


2.可到下列網址取得基本設定

http://www.yrex.com/spam/spamconfig.php


　規則CF檔放置於/etc/mail/spamassassin/即可，中文規則需用上傳不可直接複製貼上複製

3.下載中文過濾規則

wget -N -P /etc/mail/spamassassin/ www.ccert.edu.cn/spam/sa/Chinese_rules.cf



D.啟動spamassassin自動學習
1.建立bayes資料庫

spamassassin –lint –config-file=/etc/MailScanner/spam.assassin.prefs.conf -D

　無資料庫時出現debug: bayes: no dbs present, cannot tie DB R/O: /var/spool/MailScanner/spamassassin/bayes_toks
　執行sa-learn –sync在/var/spool/MailScanner/spamassassin/裡建立bayes_seen/bayes_toks等資料庫檔案

2.建立黑名單帳號

useradd spam


3.建立白名單帳號

useradd nospam


4.收到誤判或漏判信件時，”以附加檔案方式轉寄”給blacklist或whitelist

5.學習黑名單

sa-learn –prefs-file=/etc/MailScanner/spam.assassin.prefs.conf –showdots –spam –mbox /var/mail/spam


6.學習白名單

sa-learn –prefs-file=/etc/MailScanner/spam.assassin.prefs.conf –showdots –ham –mbox /var/mail/nospam


7.每小時自動學習黑/白名單
　在/etc/cron.daily建立Script

vim /etc/cron.daily/spam-learn


#!/bin/sh
SPAM=/var/mail/spam
NOSPAM=/var/mail/nospam

LOGFILE=/var/log/spamlearn.log
CONF=/etc/MailScanner/spam.assassin.prefs.conf
LEARN=/usr/bin/sa-learn

date >> $LOGFILE
if [ -f $SPAM ]; then
BOX=${SPAM}.processing
mv $SPAM $BOX
sleep 5
$LEARN –prefs-file=$CONF –spam –mbox $BOX >> $LOGFILE 2>&1
rm -f $BOX
fi

if [ -f $NOSPAM ]; then
BOX=${NOSPAM}.processing
mv $NOSPAM $BOX
sleep 5
$LEARN –prefs-file=$CONF –ham –mbox $BOX >> $LOGFILE 2>&1
rm -f $BOX
fi
#


　重新啟動crond

/etc/init.d/crond restart


来自:唉呦~MIS先生

Share
发表评论?

郵件伺服器 Part-1：Postfix+Dovecot+SASL+Procmail

发布于 2008-10-17
by

系統使用CentOS 5.1
郵件伺服器全系列：+Dovecot+SASL+Procmail+Postgrey+Mailscanner+Spamassassin+ClamAV+Mailscanner-mrtg+MailWatch+Openwebmail+MySPAM

一、移除sendmail，安裝POSFIX
/etc/init.d/sendmail stop
yum install postfix
rpm -e sendmail
chkconfig –add postfix
/etc/init.d/postfix start

二、安裝cyrus-sasl
yum install cyrus-sasl

1.設定SASL啟動
chkconfig saslauthd on
service saslauthd start

2.修改SASL設定
vim /usr/lib/sasl2/smtpd.conf

pwcheck_method: saslauthd
#mech_list: PLAIN LOGIN

三、安裝Procmail
yum install procmail

1.設定Procmail
vim /etc/procmailrc

LOGFILE=/var/log/procmail/procmail.log

(其餘指令依需求設定)

2.建立LOG檔
mkdir /var/log/procmail
touch /var/log/procmail/procmail.log
chmod 644 /var/log/procmail/procmail.log

3.設定logrotate
vim /etc/logrotate.d/procmail

/var/log/procmail/procmail.log {
monthly
size=10M
rotate 5
nocompress
}

四、安裝dovecot(pop3與imap)
yum install dovecot

1.編輯dovecot
vim /etc/dovecot.conf

啟用POP3
protocols = pop3

啟用純文字驗證功能
disable_plaintext_auth = no

偽裝歡迎訊息
login_greeting = Microsoft Exchange 2000 POP3 server version 6.0.6603.0 (ex.roc.corp) ready.

2.啟動dovecot
chkconfig dovecot on
service dovecot start

3.變更郵件檔權限
chmod a+rwxt /var/

五、設定Postfix
vim /etc/postfix/main.cf

1.對所有界面服務
#inet_interfaces = localhost
inet_interfaces = all

mail_owner = postfix
2.設定主機名稱及網域設定
mynetworks = 192.168.0.0/24, 127.0.0.0/8
mynetworks_style = host
myhostname = mail.domain.com
mydomain = domain.com

3.設定procmail過濾
mailbox_command = /usr/bin/procmail

4.設定使用SASL
EX.
#SMTP sasl Auth
smtpd_sasl_auth_enable = yes
broken_sasl_auth_clients = yes
smtpd_sasl_security_options = noanonymous
smtpd_sasl_local_domain = $myhostname
smtpd_sasl_application_name = smtpd

#開啟 smtp 認證
smtpd_sasl_auth_enable = yes

#client端的相容性
broken_sasl_auth_clients = yes

#允許sasl認證，接收本機為最後一站的信件
smtpd_recipient_restrictions = permit_sasl_authenticated permit_auth_destination rejec

#允許用戶端sasl認證
smtpd_client_restrictions = permit_sasl_authenticated

#允許非匿名的使用者
smtpd_sasl_security_options = noanonymous

#sasl的本地網域
smtpd_sasl_local_domain = $myhostname

#阻擋網域名稱錯誤
smtpd_sender_restrictions = reject_unknown_sender_domain

#阻擋動態IP的主機
smtpd_client_restrictions = check_client_access regexp:/etc/postfix/access

設定驗證項目
每個驗證項目前需空格，最後一項不加”,”

5.針對client的ip/domain設限
EX.
smtpd_client_restrictions =
permit_mynetworks,
permit_sasl_authenticated,
check_client_access hash:/etc/postfix/access,
reject_rbl_client cbl.abuseat.org,
reject_rbl_client sbl.spamhaus.org,
reject_rbl_client xbl.spamhaus.org,
reject_rbl_client dsbl.dnsbl.net.au

項目說明：
#允許內網不必檢查
permit_mynetworks,

#SASL驗證
permit_sasl_authenticated,

#反解失敗就拒絕
reject_unknown_client,

#根據access清單拒絕client
check_client_access hash:/etc/postfix/access,

(先建立/etc/postfix/access檔案,拒絕動態ip的client

dynamic.apol.com.tw REJECT We can’t allow dynamic IP to relay!
dynamic.giga.net.tw REJECT We can’t allow dynamic IP to relay!
dynamic.hinet.net REJECT We can’t allow dynamic IP to relay!
dynamic.seed.net.tw REJECT We can’t allow dynamic IP to relay!
dynamic.tfn.net.tw REJECT We can’t allow dynamic IP to relay!
dynamic.ttn.net REJECT We can’t allow dynamic IP to relay!
dynamic.lsc.net.tw REJECT We can’t allow dynamic IP to relay!

postmap hash:/etc/postfix/access 來建立DB)

#使用正規表示式拒絕名稱中有dynamic的主機連線
check_client_access regexp:/etc/postfix/access_re

(請先建立 /etc/postfix/access_re
/dynamic/ REJECT )

#使用DNS Block List 黑名單機制
reject_rbl_client cbl.abuseat.org,
reject_rbl_client sbl.spamhaus.org,
reject_rbl_client xbl.spamhaus.org,
reject_rbl_client dsbl.dnsbl.net.au,

6.要求寄信前要提出helo的要求
smtpd_helo_required = yes

7.SMTP驗證HELO
EX.
smtpd_helo_restrictions =
permit_mynetworks,
reject_invalid_hostname,
check_helo_access hash:/etc/postfix/fake_helo


#拒絕不正確/未知的helo domain
reject_invalid_hostname,
#reject_non_fqdn_hostname,
#reject_unknown_hostname,
#拒絕外界但是宣稱是自己domain的helo
check_helo_access hash:/etc/postfix/fake_helo

(拒絕外界但是宣稱是自己domain的helo
請先建立 /etc/postfix/fake_helo
內容 example.com REJECT
利用#postmap hash:/etc/postfix/fake_helo 建立DB)

#馬上拒絕不delay
smtpd_delay_reject = no

8.根據Mail from來限制
EX.
smtpd_sender_restrictions =
permit_mynetworks,
reject_non_fqdn_sender,
reject_unknown_sender_domain


#拒收來自於外界卻宣稱發自內部的信件
#check_sender_access hash:/etc/postfix/fake_from,
(建立 /etc/postfix/fake_from
內容 example.com REJECT
使用 #postmap hash:/etc/postfix/fake_from)

#拒絕不正確和未知的domain
reject_non_fqdn_sender


9.根據接收來限制
EX.
smtpd_recipient_restrictions =
permit_mynetworks,
permit_sasl_authenticated,
check_policy_service unix:/var/spool/postfix/postgrey/socket,
permit_auth_destination,
reject_unauth_destination


#有鑑於有些廣告信都是以edm@xxx.com為sender
header_checks = regexp:/etc/postfix/hc
(建立一檔案 /etc/postfix/hc
內容 /^From:.*edm@/ REJECT
使用正規表示式過濾以edm@xxx.com為寄件人的廣告信)

10.偽裝登入POSTFIX時所顯示的訊息
smtpd_banner = Welcome to Microsoft Exchange 2003

11.佇列儲存時間
#寄出時間
maximal_queue_lifetime = 5d
#退信時間
bounce_queue_lifetime = 5d

12.每封信限制大小
message_size_limit = 512000000

13.每個帳號郵箱限制大小(無限)
mailbox_size_limit = 0


——————————————————————–

SASL測試
1.啟動saslauthd啟動
/etc/rc.d/init.d/saslauthd start
service postfix reload

2.測試
testsaslauthd -u user -p ‘password’
0: OK “Success.”–>成功



3.相關設定檔
/etc/sysconfig/saslauthd

主要是MECH=shadow

4.SASL驗證訊息
saslauthd -v
saslauthd 2.1.19
authentication mechanisms: getpwent kerberos5 pam rimap shadow ldap

5.TELNET測試
telnet mail.domain.com 25

EHLO test.com

250-mail.domain.com
250-PIPELINING
250-SIZE 512000000
250-VRFY
250-ETRN
250-AUTH PLAIN LOGIN
250-AUTH=PLAIN LOGIN
250-ENHANCEDSTATUSCODES
250-8BITMIME
250 DSN

六、七行會顯示目前的認證協定
———————————————————————

POSTFIX測試

1.檢查啟動
service postfix restart
netstat -tupln grep :25

postfix在port 25 listen

2.檢查postfix設定
#postconf
檢查預設值
#postconf -d

3.Telnet寄信
Client傳送信件給Server的程序為
HELO / EHLO 網域名稱
MAIL FROM: 寄件者e-mail
RCPT TO: 收件者e-mail
DATA 信件內容然後以 . 為結束
QUIT 寄信完離開

来自:唉呦~MIS先生
本文:地址

Share
发表评论?

大家来智力一下下！

发布于 2008-10-16
by

 抽取木块是个很常见的益智类游戏，平时我们会将事先垒起来的木块逐一抽出而不能使整个木块崩塌。而抽取木块(Totem Destroyer)这个Flash小游戏也是如此，玩家需要抽取规定数量的木块而使木块之上的小金人不落地，游戏右上角会显示要抽取的木块数量。搭建的木块有三种颜色，只有绿色和棕色的木块可以用鼠标点击取走，而黑色的木块却不行。



游戏总共25关，通过之后，你可以查看全球排名，你能用最短的时间全部通过么？

来自:http://www.benmao.com/

Share
发表评论?

网站地图

发布于 2008-10-16
by


这是一个WordPress的插件,他可以显示你blog内所以有文章,以地图的方示显示给大家看这样更直接.

下载:Map地图

安装:

  • 下载sitemap-generator.zip 并解压
  • 上传 sitemap-generator 文件夹 到指定的插件目录
  • 使用管理员进入激活该插件.
  • 配置(under DDSitemapGen)
  • 在页面上添加一页面作为连接.
  • 在页面内添加内容如下:
<!-- ddsitemapgen -->
  • 注: 请使用Html 源代码页面写入上面的代码.
Share
发表评论?

虚拟紫禁城

发布于 2008-10-16
by

昨天在无意中看到中央电视台在播放一段有关”虚拟故宫——超越时空的紫禁城”

“虚拟紫禁城”(虚拟故宫）是一个三维虚拟世界，来自世界各地的游客可以在其中感受位于北京的“紫禁城”。您可以探索中国最后一个王朝 － 清王朝（1644 年 － 1912 年）宏伟的宫殿.虚拟故宫现在已经可以在网站下载，请跳跃地查看本文的超越时空的紫禁城下载（虚拟故宫下载）。
觉的还不错.网站提供三种语言(英文,简体,繁体).三种不同的操作系统平台(windows,Mac OS X,).这还真的很少见到哦…总的运行起来呀.还真的累…跑的太慢了.我的机器虽然是2G的内存.但是没有独立的显卡.所以跑起来还是一样的慢.真受不了.不过看了一下还不错.但就是不知道要看些什么.哈….





针对 Windows 的系统需求
  • 操作系统：Windows XP/Vista
  • CPU：Pentium 4 2.4GHz+ 或 AMD 2400xp+
  • 系统内存（RAM）：1GB
  • 硬盘：2GB 可用空间
  • 网速：768 Kb/s
  • 显卡：具有 128MB VRAM 的 3D 显卡
  • 屏幕：1280×1024，32 位真彩色
针对 Mac OS X 的系统需求
  • 操作系统：Mac OS X 10.4.5
  • CPU：G4 1.2Ghz 或 Intel
  • 系统内存（RAM）：1GB
  • 硬盘：2GB 可用空间
  • 网速：768 Kb/s
  • 显卡：具有 128MB VRAM 的 3D 显卡
  • 屏幕：1280×1024，32 位真彩色
针对 Linux 的系统需求
  • 操作系统：Kernel 2.6 或更高版本
    glibc 2.3.5 w/ NPTL 或更高版本
    x.org R6.7 或更高版本
  • 系统内存（RAM）：1GB
  • 硬盘：2GB 可用空间
  • 网速：768 Kb/s
  • 显卡：具有 128MB VRAM 的 3D 显卡
  • 屏幕：1280×1024，32 位颜色
Share
发表评论?
Page 144 of 175« 首页141142143144145146147148最后一页 »
